Small interface, big flexibilityDockingStations not only offer users a way to quickly change from one working environment to another via a single cable, they can also add additional functionality and capabilities to notebooks that are increasingly favoring design over function.
Appearance and performanceThis DockingStation perfectly combines high-quality appearance and efficient technology with a very compact size. The premium aluminium enclosure looks good and offers high comfort while using. This solution is suited for any location such as private or office areas.
Always informed!Three video interfaces are available, and enable you to connect HDMI® and DP™ devices simultaneously.
- WORK EFFECTIVELY: Extend or mirror your display on up to three monitors. HDMI and DisplayPort Alt Mode enable a resolution of up to 3840x2160/60 Hz
- RAPIDLY FAST: The docking station's USB 3.0 ports enable data transfer rates of up to 5 Gbps. With the LAN (RJ45) interface, you can also surf the Internet at high speed
- FULLY CHARGED: Thanks to Power Delivery, connected devices are charged with up to 100 W via an optionally available USB-C charger. This ensures that you always have enough power
- MAXIMUM COMPATIBLE: The docking station supports Windows and macOS. It is the perfect extension for MacBook, iPad Pro, Huawei MateBook X, Dell XPS 13, ThinkPad, Chromebook and more
Spezifikationen
Logistics data
| Bruttogewicht des (äußeren) Hauptkoffers | 13000 g |
| Master (äußere) Gehäusebreite | 33 cm |
| Master (äußere) Gehäusehöhe | 28 cm |
| Master (äußere) Gehäuselänge | 44 cm |
| Produkte pro Master (Außen)-Case | 60 Stück(e) |
Network
| Ethernet-LAN | Yes |
| Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| Ethernet-LAN-Datenraten | 10/100/1000 Mbit/s |
Packaging content
Packaging data
| Menge pro Packung | 1 Stück(e) |
Performance
| Datenübertragungsrate | 5 Gbit/s |
| Gehäusematerial | Aluminium/Plastic |
| HD-Typ | 4K Ultra HD |
| Kartenleser integriert | Yes |
| Kompatible Speicherkarten | MicroSD (TransFlash)/SD |
| Maximum Bildwiederholfrequenz | 60 Hz |
| Maximum digitale Auflösung | 3840 x 2160 Pixel |
| Produktfarbe | Anthracite |
Ports & interfaces
| Anzahl der HDMI-Anschlüsse | 2 |
| Anzahl der USB 2.0-Anschlüsse | 2 |
| Anzahl USB 3.2 Gen 1 (3.1 Gen 1) Typ-A Anschlüsse | 2 |
| Anzahl USB 3.2 Gen 1 (3.1 Gen 1) Typ-C Anschlüsse | 2 |
| DisplayPort-Version | 1.4 |
| DisplayPorts Menge | 1 |
| Host-Schnittstelle | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Konnektivitätstechnologie | Wired |
| Kopfhörerausgänge | 0 |
| Mikrofon rein | No |
| Überarbeitung der USB-Stromversorgung | 3.0 |
| USB Power Delivery bis zu | 100 W |
| USB-Stromversorgung | Yes |
Power
Software
| Unterstützte Windows-Betriebssysteme | Windows 10/Windows 10 Education/Windows 10 Education x64/Windows 10 Enterprise/Windows 10 Enterprise x64/Windows 10 Home/Windows 10 Home x64/Windows 10 IOT Core/Windows 10 IoT Enterprise/Windows 10 Pro/Windows 10 Pro x64/Windows 10 x64 |
Vendor information
| Brand Name | ICY BOX |
| Warranty | 2 |
