Bring diversity to the office everydayWith just one USB 3.0 host connector, you receive four further USB 2.0 ports, two USB 3.0 ports, one DVI-I and one HDMI connector as well as a Gigabit Ethernet connection and audio ports.
Multitasking for allThanks to the graphic interfaces DVI-I and HDMI, two additional screens can be connected, both in Full HD quality. The many available USB 2.0 and USB 3.0 ports make sure you will never have a need to compensate one device over the other.
Hands and feetThe high-quality metal stand makes sure the IB-DK2241AC is always in balance. Adding all the available ports, this device will make order in every situation.
- ATTENTION: DisplayLink driver must be installed before use. Display and connectivity expansion is provided by DisplayLink video compression technology
- VERTICAL AND HORIZONTAL PLACEMENT: The design of the docking station provides the user with the flexibility for vertical or horizontal placement that fits well with the layout of their office décor
- MULTIPLE EXPANSION: With just one cable, users can transform their notebook into a desktop workstation with six additional USB ports, DVI-I & HDMI, Gigabit Ethernet and two audio inputs/outputs
- DUAL VIDEO OUTPUT: Two 2K@60 Hz DVI-I & HDMI outputs can be used to connect additional monitors and expand the overall experience
- COST-EFFICIENT DESIGN: The docking station offers the best value for money. It looks good, has a wide range of features and is affordable. Operating systems such as Windows and macOS are supported
- DRIVER INSTALLATION REQUIRED
Spezifikationen
Logistics data
| Bruttogewicht des (äußeren) Hauptkoffers | 8500 g |
| Master (äußere) Gehäusebreite | 21.5 cm |
| Master (äußere) Gehäusehöhe | 33 cm |
| Master (äußere) Gehäuselänge | 35.7 cm |
| Produkte pro Master (Außen)-Case | 10 Stück(e) |
Network
| Ethernet-LAN | Yes |
| Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| Ethernet-LAN-Datenraten | 10/100/1000 Mbit/s |
Other features
| Anzahl der Mikrofoneingänge | 1 |
Packaging content
| Handbuch | Yes |
| Inklusive Netzteil | Yes |
| Kabel enthalten | USB |
Packaging data
| Menge pro Packung | 1 Stück(e) |
Performance
| Anzahl der unterstützten Displays | 2 |
| Datenübertragungsrate | 5 Gbit/s |
| Gehäusematerial | Acrylonitrile butadiene styrene (ABS)/Metal/Polycarbonate (PC) |
| HD-Typ | 2K |
| Hot-Plug-Unterstützung | Yes |
| Kartenleser integriert | No |
| Ladefunktion | Yes |
| LED-Anzeigen | Yes |
| Markenkompatibilität | Any brand |
| Maximum digitale Auflösung | 2048 x 1152 Pixel |
| Plug-and-Play | Yes |
| Produktfarbe | Black |
Ports & interfaces
| Anzahl der DVI-I-Anschlüsse | 1 |
| Anzahl der HDMI-Anschlüsse | 1 |
| Anzahl der USB 2.0-Anschlüsse | 4 |
| Anzahl USB 3.2 Gen 1 (3.1 Gen 1) Typ-A Anschlüsse | 2 |
| Host-Schnittstelle | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| Konnektivitätstechnologie | Wired |
| Kopfhöreranschluss | 3.5 mm |
| Kopfhörerausgänge | 1 |
| Mikrofon rein | Yes |
Power
| AC-Eingangsspannung | 100-240 V |
| Ausgangsspannung | 5 V |
| Ausgangsstrom | 4 A |
| Stromquellentyp | AC |
| Stromverbrauch (max.) | 20 W |
Software
| Unterstützte Mac-Betriebssysteme | Yes |
| Unterstützte Windows-Betriebssysteme | Yes |
Vendor information
| Brand Name | ICY BOX |
| Warranty | 2 |
