PE4102G-AT-G

Engineered to be an intelligent power distribution solution, the PE4102G Eco PDU Power Controller ships with 2 power outlets in an IEC socket configuration. It provides secure, centralized, intelligent, and remote power management of data center IT equipment to minimize operating costs.

The PE4102G features the remote power control function, allowing you to control devices attached to the PDU at the PDU device level from practically any location via a TCP/IP connection. The power sequence design eliminates the risks of power inrush, guaranteeing reliable operation and protecting the overall system health. With the support for eco DC software, it provides an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and reboot the device in case any equipment lock-up occurs. Additionally, the auto ping and auto reboot functions ensure devices remain responsive by automatically detecting connection issues and rebooting when necessary. Administrators can switch on/off or set a delay time for each power outlet or individual power outlet group whenever, wherever.

The PE4102G boasts a slim, compact form factor and supports desk mount, wall mount, as well as rack mount, ensuring easy installation in confined spaces. It is a smart eco PDU power controller tailored for hospitality or retail applications, such as digital signage and video walls, for edge computing devices, including routers, servers, and cameras, or for any data center environments where there is no need to keep the servers powered on at all times.

ATEN PE4102G. PDU types: Managed, Mounting type: Desk/Wall, Product color: Black. AC outlets quantity: 2 AC outlet(s), AC outlet types: C13 coupler, Power plug: C14 coupler. Cable length: 118.1" (3 m). Supported network protocols: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3. Nominal input voltage: 100 - 240 V, Maximum current: 10 A, AC input frequency: 50 - 60 Hz

PDU types	Managed
Rack mounting	Yes
Mounting type	Desk/Wall
Product color	Black
AC outlets quantity	2 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C14 coupler
Ethernet LAN (RJ-45) ports	1
Cable length	118.1" (3 m)
Password protection	Yes
Supported network protocols	TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3
Nominal input voltage	100 - 240 V
Maximum current	10 A
AC input frequency	50 - 60 Hz
Nominal output voltage	100 - 240 V
Load capacity	2400 VA
Compliance certificates	Low Voltage Directive (LVD), CE, Electromagnetic Compatibility (EMC)
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Width	5.03" (127.8 mm)
Depth	6.69" (170 mm)
Height	1.73" (44 mm)
Weight	34.6 oz (980 g)
Cables included	AC
Manual	Yes
Package weight	2.8 lbs (1.27 kg)
Package width	3.74" (95 mm)
Package depth	10.4" (265 mm)
Package height	8.66" (220 mm)
Package volume	5550.101932032 cm³
Country of origin	China
Master (outer) case net weight	10.8 lbs (4.9 kg)
Master (outer) case width	9.13" (232 mm)
Master (outer) case length	19.7" (500 mm)
Master (outer) case height	11.1" (283 mm)
Master (outer) case weight	15.3 lbs (6.92 kg)
Master (outer) case volume	32819.225200128 cm³
