Riferimento: ST3450857SS
Marca: Seagate
ST3450857SS _ RFB
Seagate Cheetah 450GB 3.5, 450 GB, 15000 Giri/min, 16 MB, 3.5", SAS
56,2 CHF
tasse incl.
52,0 CHF
tasse escl.
In magazzino
Riferimento: 110900
Marca: Brady
M21-500-430
Polyester tape for M211 M210 BMP21-PLUS BMP21-LAB BMP21 Polyester
67,2 CHF
tasse incl.
62,2 CHF
tasse escl.
Verrà ordinato per te
37,0 CHF
tasse incl.
34,2 CHF
tasse escl.
In magazzino
RP000121357
Intel Xeon Processor E5506 (4M Cache, 2.13 GHz, 4.80 GT/s Intel QPI)
Descrizione
The Intel® Xeon® processor 5500 series automatically and intelligently adjusts server performance according to your application needs for an up to 9x performance gain over single-core servers1 at 18 percent less operating power. This enables you to achieve a 9:1 server consolidation ratio, reducing operating costs by up to 90 percent resulting in an estimated 8-month return on a new server investment. Click here to estimate the business benefits of refreshing your server environment.
Intelligent next-generation Intel® microarchitecture adapts to the workload, automatically increasing processor frequency for greater performance.
Better performance enabled by Intel® Turbo Boost Technology, increasing processor frequency and enabling faster speeds when conditions allow.
Lower energy costs while minimizing impact to performance by automatically putting processor and memory into the lowest available power state.
Individual cores are reduced to near-zero power independent of other operating cores.
Virtualize different generations of Intel® Xeon® processor–based servers in the same pool to deliver peak performance during high-use periods and automatically reduce energy cost during low-use periods.
Integrates multiple generations of Intel® Xeon® processor-based servers, improving flexibility for failover, load balancing, and disaster recovery.
Flexibility for 64-bit and 32-bit applications and operating systems.
- Up to 64 GB/s for three times the memory bandwidth over previous memory technology;
- Up to 144GB supports higher performance for data-intensive applications;
- Enhanced reliability, availability, and serviceability features.
- Moves data more efficiently for fast, scalable, and reliable network performance;
- Ability to significantly reduce CPU overhead, freeing resources for more critical tasks.
- Many memory controller features, together with PCI Express RAS features, combine to help improve platform reliability vs. previous-generation platforms;
- New features include Error Correcting Code (ECC) system bus, new memory mirroring and I/O hot-plug.
Intelligent next-generation Intel® microarchitecture adapts to the workload, automatically increasing processor frequency for greater performance.
Better performance enabled by Intel® Turbo Boost Technology, increasing processor frequency and enabling faster speeds when conditions allow.
Lower energy costs while minimizing impact to performance by automatically putting processor and memory into the lowest available power state.
Individual cores are reduced to near-zero power independent of other operating cores.
Virtualize different generations of Intel® Xeon® processor–based servers in the same pool to deliver peak performance during high-use periods and automatically reduce energy cost during low-use periods.
Integrates multiple generations of Intel® Xeon® processor-based servers, improving flexibility for failover, load balancing, and disaster recovery.
Flexibility for 64-bit and 32-bit applications and operating systems.
- Up to 64 GB/s for three times the memory bandwidth over previous memory technology;
- Up to 144GB supports higher performance for data-intensive applications;
- Enhanced reliability, availability, and serviceability features.
- Moves data more efficiently for fast, scalable, and reliable network performance;
- Ability to significantly reduce CPU overhead, freeing resources for more critical tasks.
- Many memory controller features, together with PCI Express RAS features, combine to help improve platform reliability vs. previous-generation platforms;
- New features include Error Correcting Code (ECC) system bus, new memory mirroring and I/O hot-plug.
Specifiche
Features
| CPU configuration (max) | 2 |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Market segment | Server |
| Physical Address Extension (PAE) | Yes |
Graphics
| On-board graphics card | No |
Memory
| ECC | Yes |
| Maximum internal memory supported by processor | 144 GB |
| Memory channels | Triple-channel |
| Memory clock speeds supported by processor | 800 MHz |
| Memory types supported by processor | DDR3-SDRAM |
Operational conditions
| Tcase | 76 °C |
Other features
| Intel® Virtualization Technology (Intel® VT) | VT-d/VT-x |
Processor
| Bus type | QPI |
| Compatible chipsets | Intel® 5500/Intel® 5520 |
| Component for | Server/workstation |
| Memory bandwidth supported by processor (max) | 19.2 GB/s |
| Number of QPI links | 2 |
| Processor base frequency | 2.13 GHz |
| Processor cache | 4 MB |
| Processor cache type | L3 |
| Processor cores | 4 |
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor frequency | 2.13 GHz |
| Processor lithography | 45 nm |
| Processor model | E5506 |
| Processor operating modes | 64-bit |
| Processor socket | Socket B (LGA 1366) |
| Processor threads | 4 |
| Stepping | D0 |
| System bus rate | 4.8 GT/s |
| Thermal Design Power (TDP) | 80 W |
| VID Voltage Range | 0.75 - 1.35 V |
Processor special features
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Demand Based Switching | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Smart Cache | Yes |
Vendor information
| Brand Name | Hewlett Packard Enterprise |
| Warranty | 1 |
Dettagli del prodotto
506013-001
4 Articoli
imesso a nuovo
Scheda tecnica
- Data Integrity Check (verifica integrità dati)
- Yes
- Tcase
- 76 °C
- Intel® Smart Cache
- Sì
- Prozessorkerne
- 4
- Prozessormodell
- E5506
- Prozessorfrequenz
- 2.13 GHz
- komponente_fur
- Server/workstation
- Brand Name
- Hewlett Packard Enterprise
- Warranty
- 1
- CPU-Konfiguration (max.)
- 2
- Disable-Bit ausführen
- Yes
- Marktsegment
- Server
- Onboard-Grafikkarte
- No
- Maximum interner Speicher, der vom Prozessor unterstützt wird
- 144 GB
- Speicherkanäle
- Triple-channel
- Vom Prozessor unterstützte Speichertaktraten
- 800 MHz
- Vom Prozessor unterstützte Speichertypen
- DDR3-SDRAM
- Intel Virtualisierungstechnik (Intel VT)
- VT-d/VT-x
- Betriebsmodi des Prozessors
- 64-bit
- Bustyp
- QPI
- Grundfrequenz des Prozessors
- 2.13 GHz
- Prozessor-Cache
- 4 MB
- Prozessor-Cache-Typ
- L3
- Prozessor-Threads
- 4
- Prozessorfamilie
- Intel® Xeon® 5000 Sequence
- Prozessorlithographie
- 45 nm
- Prozessorsockel
- Socket B (LGA 1366)
- Systembusrate
- 4.8 GT/s
- Thermische Designleistung (TDP)
- 80 W
- Intel -Virtualisierungstechnologie (VT-x)
- Yes
- Intel -Virtualisierungstechnologie für Directed I/O (VT-d)
- Yes
- Intel VT-x mit erweiterten Seitentabellen (EPT)
- Yes
- Verbesserte Intel SpeedStep-Technologie
- Yes
- Ruhezustände
- Yes
- Anzahl der QPI-Links
- 2
- Kompatible Chipsätze
- Intel® 5500/Intel® 5520
- VID-Spannungsbereich
- 0.75 - 1.35 V
- Vom Prozessor unterstützte Speicherbandbreite (max.)
- 19.2 GB/s
- Bedarfsbasiertes Switching von Intel
- Yes
- Treten
- D0
- Physische Adresserweiterung (PAE)
- Yes
Riferimenti Specifici
- isbn
- 978-1-23456-789-0
- ean13
- 5712505255766
- MPN
- RP000121357
