Reinvent docking and boost productivity with our most versatile Thunderbolt™ dock, the small, sophisticated HP Thunderbolt Dock G2. Designed for workspace flexibility and network manageability, it delivers USB-C™ device connectivity and optional integrated audio.
Command your workspace from just one USB-C™ connection- Connect a single USB-C™ cable to your notebook to access a wired network, data, video, and charging with a dock that supports both HP and non-HP Thunderbolt™ and USB-C™ notebooks.
Reset your perception- Reclaim your work area with this space-saving centerpiece that helps create a clean desk. Its elegant, black, rounded design with smooth accents changes everything you thought you knew about docks.
Manage your enterprise fleet like a boss- Help IT easily secure and remotely manage a wide range of HP notebooks and the dock with advanced network manageability features built into the dock, including WoL and MAC Address Pass-Through in all power states and PXE Boot.
Maximize your multi-tasking- See every color and detail of your projects with a superfast connection to dual external 4K displays as soon as you plug your notebook into the dock.
Now hear this- Take calls without a headset with our first Thunderbolt™ dock with an audio conferencing solution. The optional HP TB Dock Audio Module attaches vertically to the dock with no cabling.
Lock it down- Secure the base dock to a desk, table or your notebook through the lock slot with an optional HP lock.
Specifiche
Network
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 35 °C |
Performance
| Brand compatibility | HP |
| Cable lock slot | Yes |
| Card reader integrated | No |
| Compatibility | HP Elite x2 1012 G1; HP Elite x2 1012 G2; HP Pro x2 612 G2; HP EliteBook Folio G1; HP EliteBook x360 1030 G2; HP EliteBook x360 1020 G2; HP EliteBook 1040 G4; HP EliteBook 800 G5; HP EliteBook 700 G5; HP ProBook 600 G4; HP ProBook 400 G5; ZBook 14u G5; ZBook 15u G5 |
| HP segment | Business |
| Product colour | Black |
Ports & interfaces
| Combo headphone/mic port | Yes |
| Connectivity technology | Wired |
| DisplayPorts quantity | 2 |
| Host interface | Thunderbolt |
| Microphone in | No |
| Thunderbolt ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
Power
| Power consumption (typical) | 120 W |
Software
| Other operating systems supported | iOS |
| Windows operating systems supported | Windows 10/Windows 7 |
