DK-1623-A-VH-305
CAT 6A U-FTP installation cable, 500 MHz Eca (EN 50575), AWG 23/1, 305 m drum, sx, blue
Descrizione
Future-oriented standards and high-end quality for your network.
- 10GBit Ethernet
- 500 MHz transmission frequency
- PoE Power over Ethernet support
- CPR class Eca
The Digitus® Cat.6A U/FTP installation cable is characterized by the following cable construction 4x2x AWG23/1 and reaches a transmission frequency up to 500 MHz. The halogen free cable jacket is conform to the standard IEC 60332-1, FRNC-B, LSZH-1 and CPR Euro class Eca. The cable is suitable for building structured cabling in the secondary and tertiary area. Compliant with the following standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-10-1.
- 10GBit Ethernet
- 500 MHz transmission frequency
- PoE Power over Ethernet support
- CPR class Eca
The Digitus® Cat.6A U/FTP installation cable is characterized by the following cable construction 4x2x AWG23/1 and reaches a transmission frequency up to 500 MHz. The halogen free cable jacket is conform to the standard IEC 60332-1, FRNC-B, LSZH-1 and CPR Euro class Eca. The cable is suitable for building structured cabling in the secondary and tertiary area. Compliant with the following standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-10-1.
- Physical properties:
- Conductor: Bare annealed copper, solid AWG 23/1
- Total number of insulated conductors: 8, twisted in 4 pairs
- Color code: Blue-white, orange-white, green-white, brown-white
- Individual pair shielding: Aluminum foil, providing 100 % coverage
- Overall shielding: None, with drain wire
- Outer sheath: Eca to B2ca acc. to EN 50575; LSZH
- Outer sheath color: Light blue (RAL 5012)
- Mechanical properties:
- Tensile loading: 150N max.
- Dynamic bending radius: 8x AD mm min.
- Static bending radius: 4x AD mm min.
- Shipping- and storage temperature range: -20 °C up to +60 °C
- Operating temperature range: -20 °C up to +75 °C
- Installation temperature range: 0 °C up to +50 °C
- Overall diameter Simplex (nominal): 7.0 (Eca); 7,2 mm (Dca); 7,6 mm (Cca); 7,6 mm (B2ca)
- Weight (kg/km): 56 kg (Eca); 57 kg (Dca); 58 kg (Cca); 58 kg (B2ca)
- Electrical properties:
- Impedance: 100±15 Ohm @ 4 - 100MHz; 100±25 Ohm @100-500 MHz
- Capacitance: 45 pF/m nominal @ 1 KHz
- Capacitance unbalance (pair-ground): 1.6 pF/m max. @ 1 KHz
- Insulation resistance: 5 GOhm x km min.
- DC loop resistance: 190 Ohm/km max. (2% max. resistance unbalance)
- Voltage resistance: 72 Vdc max.
- Coupling attenuation: CA-Type 2
- Signal propagation delay: 450 nS/100 m max.
- Propagation delay: 25 nS/100 m max.
- Separating class: ,,c” acc. to EN 50174-2
- NVP: 70%
Specifiche
Features
| AWG wire size | 23/1 |
| Cable length | 305 m |
| Cable shielding | U/FTP (STP) |
| Cable standard | Cat6a |
| Certification | CPR class Eca |
| Conductor type | Solid |
| Connector 1 | No |
| Connector 2 | No |
| Frequency | 500 MHz |
| Jacket material | Low smoke zero halogen (LSZH) |
| Product colour | Blue |
Logistics data
| UK Trade Tariff code | 85444920 |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Packaging data
| Package volume | 30118 cm³ |
Vendor information
| Brand Name | Digitus |
| Warranty | 2 |
Dettagli del prodotto
2026-06-08
Nuovo
Scheda tecnica
- Paketvolumen
- 30118 cm³
- Zertifizierung
- CPR class Eca
- Jackenmaterial
- Low smoke zero halogen (LSZH)
- Frequenz
- 500 MHz
- Kabelabschirmung
- U/FTP (STP)
- Kabelstandard
- Cat6a
- Leitertyp
- Solid
- Kabellänge
- 305 m
- Stecker 1
- No
- Stecker 2
- No
- AWG-Drahtgröße
- 23/1
- Brand Name
- Digitus
- Warranty
- 2
- Betriebstemperatur (TT)
- 0 - 50 °C
- Lagertemperatur (TT)
- -20 - 60 °C
- Produktfarbe
- Blue
- Code des britischen Handelstarifs
- 85444920
Riferimenti Specifici
- ean13
- 4016032344124
- MPN
- DK-1623-A-VH-305
