Cisco® 1100 Series Integrated Services Routers (ISRs) with Cisco IOS® XE Software combine Internet access, comprehensive security, and wireless services (LTE Advanced 3.0 wireless WAN and 802.11ac wireless LAN) in a single, high-performance device. The routers are easy to deploy and manage, with cutting-edge, scalable, multicore separate data and control plane capabilities.
The Cisco 1100 Series ISRs are well suited for deployment as Customer Premises Equipment (CPE) in enterprise branch offices and in service provider managed environments.
- PORT COUNT: 4-port managed Gigabit Ethernet switch (2 ports PoE capable with 1 port PoE+)
- CONNECTIVITY: Gigabit WAN and WAN/SFP combo ports with integrated USB 3.0 AUX/console
- SECURITY: Multi-layer, robust security and high-performance VPNs encrypt all data from the WAN edge to the cloud
- PERFORMANCE: Business router designed for broadband network speeds while running secure, concurrent data, voice, video and wireless services
- PEACE OF MIND: 1-year limited hardware warranty with 10-day advanced replacement
Specifications
Antenna
| Antenna type | Not supported |
Design
Features
| Flash memory | 4096 MB |
| Internal memory | 4096 MB |
Logistics data
Management features
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Network
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Multicast support | Yes |
| Policy-based routing | Yes |
| Static route | Yes |
Operational conditions
| Non-operating altitude | 0 - 4570 m |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 10 - 85 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | 0 - 65 °C |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 4 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
Power
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power over Ethernet (PoE) | Yes |
Protocols
| Routing protocols | BGP/EIGRP/HSRP/IS-IS/OSPF/RIP-1/RIP-2/VRRP |
Security
| Access Control List (ACL) | Yes |
| Firewall | Yes |
| Security algorithms | 3DES/802.1x RADIUS/AES/DES |
Vendor information
| Brand Name | Cisco SB |
| Warranty | 1 |
WAN connection
