SM-A566BZKAEEE

Data sheet

Product color

Graphite

Headphone connectivity

USB Type-C

Weight

6.98 oz (198 g)

Display diagonal

6.7"

Display resolution

2340 x 1080 pixels

Processor family

Samsung Exynos

Processor cores

8

Processor model

1580

Processor boost frequency

2.9 GHz

Width

3.05" (77.5 mm)

Height

6.39" (162.2 mm)

Fingerprint reader

Yes

Depth

0.291" (7.4 mm)

USB connector type

USB Type-C

AC adapter included

No

Panel type

AMOLED

Processor frequency

1.9 GHz

Internal storage capacity

128 GB

Compatible memory cards

Not supported

Rear camera type

Triple camera

Rear camera resolution (numeric)

50 MP

Front camera resolution (numeric)

12 MP

Top Wi-Fi standard

Wi-Fi 6 (802.11ax)

Bluetooth

Yes

Bluetooth version

5.3

Wi-Fi standards

Position location

Yes

GPS (satellite)

Yes

Accelerometer

Yes

Ambient light sensor

Yes

Gyroscope

Yes

Platform

Android

Continuous video playback time

29 h

Cables included

USB Type-C to USB Type-C

USB version

2.0

USB Power Delivery

Yes

Maximum refresh rate

120 Hz

Maximum frame rate

240 fps

Auto focus

Yes

Digital zoom

10x

Screen shape

Flat

Display number of colors

16 million colors

Energy efficiency scale

A to G

USB Type-C charging port

Yes

MIMO

Yes

Modulation

1024-QAM

International Protection (IP) code

IP67

Video formats supported

3G2, 3GP, AVI, FLV, M4V, MKV, MP4, WEBM

Audio formats supported

3GA, AAC, AMR, AWB, FLAC, IMY, M4A, Mid, MIDI, MP3, MXMF, OGA, OGG, OTA, RTTTL, RTX, WAV, XMF

RAM capacity

8 GB

Mobile network generation

5G

3G standards

UMTS, WCDMA

4G standard

LTE-TDD & LTE-FDD

Fast charging

Yes

Video call

Yes

Video resolutions

3840 x 2160 pixels

Resolution at capture speed

1280x720@240fps, 3840x2160@30fps

4G bands supported

Hearing aid compatibility

Yes

Short Message Service (SMS)

Yes

Color name

Awesome Graphite

User memory

106.4 GB

Required charging power (min)

10 W

Required charging power (max)

45 W

Proximity sensor

Yes

SIM card type

NanoSIM + eSIM

5G standard

Sub6 FDD, Sub6 TDD

Wi-Fi Direct

Yes

Image stabilizer

Yes

Electronic compass

Yes

Removable battery

No

Formfaktor

Bar

Energy efficiency class

B

Display glass type

Gorilla Glass

Gorilla Glass version

Gorilla Glass Victus+

Front camera type

Single camera

Rear camera flash

Yes

Second rear camera resolution (numeric)

12 MP

Third rear camera resolution (numeric)

5 MP

Rear camera aperture number

1.8

SIM card capability

Dual SIM

Multimedia Messaging Service (MMS)

Yes

E-mail

Yes

GLONASS

Yes

BeiDou

Yes

Galileo

Yes

Quasi-Zenith Satellite System (QZSS)

Yes

Speakers

stereo

App distribution platform

Google Play

SIM card ejector pin

Yes

3G bands supported

850,900,1900,2100 MHz

Front camera aperture number

2.2

5G bands supported

Second rear camera aperture number

2.2

Display technology marketing name

Super AMOLED

Third rear camera aperture number

2.4

Image stabilizer type

Optical Image Stabilization (OIS)

Macro photography

Yes

Battery endurance per cycle

2674 min

Battery endurance in cycles

2000

Repeated free fall reliability class

A

Repairability class

C

Slow motion mode

Yes

Battery capacity

5000 mAh

Near Field Communication (NFC)

Yes

Specific References

EAN13

8806097293309

MPN

SM-A566BZKAEEE
