C31CH63012A0

Data sheet

Type

POS printer

Product color

White

Quantity per pack

1 pc(s)

Connectivity technology

Wired

USB 2.0 ports quantity

4

Ethernet LAN

Yes

Card reader integrated

Yes

Weight

6.39 lbs (2.9 kg)

Harmonized System (HS) code

84433210

Wi-Fi

No

Maximum resolution

203 x 203 DPI

Width

5.51" (140 mm)

Height

10" (255 mm)

Country of origin

Philippines

Power source type

AC

Depth

8.43" (214 mm)

Package weight

8.4 lbs (3.81 kg)

Package width

7.87" (200 mm)

Package depth

12.3" (312 mm)

Package height

12.8" (325 mm)

Operating temperature (T-T)

5 - 45 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

10 - 90%

Print technology

Direct thermal

Compatible memory cards

MicroSD (TransFlash)

USB connectivity

Yes

Page description languages

ANK

Pallet weight

0 oz (0 g)

Quantity per pallet

72 pc(s)

Power plug type

Type G

Quantity per pallet (UK)

96 pc(s)

Mean time between failures (MTBF)

360000 h

Sound pressure level (printing)

55 dB

Print speed

250 mm/sec

Buffer size

12 KB

Pallet weight (UK)

0 oz (0 g)

Cutter

Yes

Maximum printing width

3.15" (8 cm)

Maximum roll diameter

3.27" (8.3 cm)

Supported paper width

58 mm - 80 mm (Breite)

Print head life

150 million characters
150 km
150.000.000 Impulse

USB connector

USB Type-A / USB Type-B

Printing characters

Text, Graphic, Barcode

Character sets

ANK

Autocutter durability

2.2 million cuts

Mounting position

Vertical

Column capacity

48/57

Mean cycles between failures (MCBF)

65000000

Half-cutter

Yes

Print speed (receipt)

250 mm/sec

Tablet charge & sync

Yes

Built-in sensors details

Paper End Sensor, Paper Near End Sensor, Papier-Sensor

Lifetime

17000000 lines

Specific References

EAN13

8715946689272

MPN

C31CH63012A0
