C31CD70652 - C31CD70552

Data sheet

Type

POS printer

Product color

Black

Quantity per pack

1 pc(s)

Connectivity technology

Wired & Wireless

USB 2.0 ports quantity

1

Ethernet LAN

No

Weight

17.6 oz (500 g)

Harmonized System (HS) code

84433210

Wi-Fi

No

Maximum resolution

203 x 203 DPI

Width

4.33" (110 mm)

Height

2.52" (64 mm)

Country of origin

China

Certification

FCC-Class A, CE

Depth

5.51" (140 mm)

Package weight

3.53 lbs (1.6 kg)

Package width

7.48" (190 mm)

Package depth

9.25" (235 mm)

Package height

172 mm

Storage temperature (T-T)

-25 - 70 °C

Operating relative humidity (H-H)

10 - 90%

Print technology

Direct thermal

Bluetooth

Yes

Cables included

AC, USB

Battery life (max)

46 h

USB connectivity

Yes

Page description languages

ANK

Standard interfaces

Bluetooth, USB 2.0

Pallet weight

0 oz (0 g)

Quantity per pallet

160 pc(s)

Power plug type

Type C

Pallet width

31.5" (80 cm)

Pallet length

47.2" (120 cm)

Pallet height

37.4" (95 cm)

Quantity per pallet layer

32 pc(s)

Quantity per pallet layer (UK)

48 pc(s)

Quantity per pallet (UK)

240 pc(s)

Pallet length (UK)

47.2" (120 cm)

Pallet width (UK)

39.4" (100 cm)

Pallet height (UK)

37.4" (95 cm)

Mean time between failures (MTBF)

120000 h

Sound pressure level (printing)

53 dB

Print speed

100 mm/sec

Safety

UL, CSA

Buffer size

0.128 KB

Pallet weight (UK)

0 oz (0 g)

Printing media thickness

50 - 80 µm

Maximum roll diameter

2.01" (5.1 cm)

Media thickness

0.05 - 0.08 mm

Supported paper width

79.5 mm

USB connector

Mini-USB Type-B

Character sets

ANK

Print head life

50 km
50 km - 100.000.000 Impulse

Mounting position

Horizontal/Vertical

Mean cycles between failures (MCBF)

16000000

Print speed (receipt)

100 mm/sec

Lifetime

10000000 lines

Paper size roll paper

79.50 ± 0.50 (W) mm x dia 51.00 mm

Specific References

EAN13

8715946602615

MPN

C31CD70652
