7ZT7A00546 - 7ZT7A00546

Name: Lenovo 7ZT7A00546
Brand: Lenovo
SKU: 7ZT7A00546
Price: 133.8 CHF
Availability: InStock

Reference 7ZT7A00546

Brand Lenovo

Lenovo 7ZT7A00546, Internal, Wired, PCI Express, Fiber, 10000 Mbit/s, Green, Metallic

CHF133.8

Tax included

CHF123.8 Tax excluded

Delivery in 4-5 days

Quantity

In stock

In stock: 102 Items

Description
Product Details

Description

The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.

ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.

The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.

Lenovo 7ZT7A00546. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Fiber. Maximum data transfer rate: 10000 Mbit/s. Product color: Green, Metallic

Connectivity technology	Wired
Host interface	PCI Express
Interface	Fiber
Fiber ports quantity	2
Maximum data transfer rate	10000 Mbit/s
Networking standards	IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x
Ethernet LAN	Yes
Ethernet LAN data rates	10000 Mbit/s
Security algorithms	SNMP
Jumbo frames support	Yes
Jumbo frames	9728
Quality of Service (QoS) support	Yes
VLAN tagging	Yes
Internal	Yes
Product color	Green, Metallic
Chipset	Intel® C624
Certification	UL recognized to UL60950-1 2nd Edition FCC Rules, Part 15, Class A Australian EMC Framework (RCM) Japan VCCI, Class A Industry Canada, ICES-003, Class A EU (CE Mark) Korea KC-RRA, Class A
Compatible products	SR630 SR650 SR850 SR860 SR950
Other operating systems supported	VMware vSphere ESXi
Server operating systems supported	SUSE Linux Enterprise Server 11, SUSE Linux Enterprise Server 12, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016
Compliance certificates	RoHS
Harmonized System (HS) code	85176990
Flow control support	Yes
Number of VLANs	4096
Intel Virtual Machine Device Queues (VMDq)	Yes
PCI-SIG* SR-IOV Capable	Yes
Intel Data Direct I/O Technology	Yes
Receive Side Scaling (RSS)	Yes

Product Details

Reference 7ZT7A00546

In stock 102 Items

Condition New

Data sheet

Product color: Green, Metallic
Interface: Fiber
Connectivity technology: Wired
Host interface: PCI Express
Ethernet LAN: Yes
Ethernet LAN data rates: 10000 Mbit/s
Harmonized System (HS) code: 85176990
Compatible products: SR630
SR650
SR850
SR860
SR950
Internal: Yes
Certification: UL recognized to UL60950-1 2nd Edition
FCC Rules, Part 15, Class A
Australian EMC Framework (RCM)
Japan VCCI, Class A
Industry Canada, ICES-003, Class A
EU (CE Mark)
Korea KC-RRA, Class A
Maximum data transfer rate: 10000 Mbit/s
Other operating systems supported: VMware vSphere ESXi
Networking standards: IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x
Compliance certificates: RoHS
Security algorithms: SNMP
Fiber ports quantity: 2
VLAN tagging: Yes
Quality of Service (QoS) support: Yes
Jumbo frames support: Yes
Jumbo frames: 9728
Chipset: Intel® C624
Flow control support: Yes
Number of VLANs: 4096
Server operating systems supported: SUSE Linux Enterprise Server 11, SUSE Linux Enterprise Server 12, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016
PCI-SIG* SR-IOV Capable: Yes
Receive Side Scaling (RSS): Yes
Intel Virtual Machine Device Queues (VMDq): Yes
Intel Data Direct I/O Technology: Yes
