C11CF38401

Data sheet

Product color

Black

Quantity per pack

1 pc(s)

Connectivity technology

Wired

Weight

18.5 lbs (8.37 kg)

Harmonized System (HS) code

84433210

Maximum resolution

240 x 144 DPI

Width

24.1" (612 mm)

Height

6.97" (177 mm)

Country of origin

Indonesia

AC input voltage

198-264 V

Depth

14.8" (375 mm)

Package weight

26.7 lbs (12.1 kg)

Package width

17.9" (455 mm)

Package depth

28.9" (735 mm)

Package height

11.8" (300 mm)

Operating temperature (T-T)

5 - 35 °C

Storage temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

10 - 80%

Storage relative humidity (H-H)

30 - 60%

Print technology

Dot matrix

Maximum number of copies

6 copies

Page description languages

ESC P, PPDS

Paper tray media types

Envelopes

Maximum print size

A3 (297 x 420 mm)

Standard interfaces

Parallel, USB

Power consumption (standby)

8 W

Sustainability certificates

ENERGY STAR

Pallet weight

0 oz (0 g)

Quantity per pallet

14 pc(s)

Color

No

Power consumption (typical)

54 W

Pallet width

31.5" (80 cm)

Pallet length

47.2" (120 cm)

Pallet height

88.6" (2.25 m)

Quantity per pallet layer

2 pc(s)

Quantity per pallet layer (UK)

3 pc(s)

Quantity per pallet (UK)

21 pc(s)

Pallet length (UK)

47.2" (120 cm)

Pallet width (UK)

39.4" (100 cm)

Pallet height (UK)

88.6" (2.25 m)

Mean time between failures (MTBF)

25000 h

Sound pressure level (printing)

55 dB

Buffer size

128 KB

Pallet weight (UK)

0 oz (0 g)

Built-in barcodes

CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E

Print head

9-pin

Power consumption (economy mode)

0.5 W

Maximum printing width (columns)

136

Print head life

400 million characters

Number of characters

42

Character sets

PCAPTEC, PC437, PC720, PC850, PC858, ISO 8859-15, Roman 8, Italic

Print yield

12 characters

Maximum print speed

738 cps

Maximum print speed (draft)

463 cps

Continuous paper thickness range

0.0181 - 0.0181" (0.46 - 0.46 mm)

Label thickness range

0.0181 - 0.0181" (0.46 - 0.46 mm)

Multi-part paper thickness range

0.00472 - 0.0181" (0.12 - 0.46 mm)

Single sheet thickness range

0.00236 - 0.00551" (0.0600 - 0.14 mm)

Maximum print speed (NLQ)

115 cps

Character pitch

10,12,15 cpi

Bitmap fonts

Draft, OCR-B, Roman, Sans Serif

Needles

18 (2 x 9)

Print direction

Bidirectional

Ribbon life (black, draft)

12 million characters

Specific References

ISBN

978-1-23456-789-0

EAN13

8715946645636

MPN

C11CF38401
