Description
Your premium UniFi doorbell with integrated PoE and included PoE chime for plug-and-play installation.
- Improved HDR and low-light performance
- Programmable welcome display and secondary package-detection camera
- AI event detections
- Connect and power using PoE
- Integrated 2-way audio
- Includes PoE Chime
- Weather-resistant (outdoor covered)
Specifications
Camera
| Built-in camera | Yes |
| Diagonal field of view | 155 ° |
| Horizontal field of view | 138 ° |
| Maximum frame rate | 30 fps |
| Maximum video resolution | 1600 x 1200 pixels |
| Megapixel (approx.) | 5 MP |
| Night vision | Yes |
| Second camera resolution | 8 MP |
| Sensor type | CMOS |
| Vertical field of view | 114 ° |
Features
| Audio system | 2-way |
| Best uses | Home |
| Certification | CE, FCC, IC |
| Housing material | Aluminium/Polycarbonate (PC) |
| Illuminated push button | Yes |
| International Protection (IP) code | IPX4 |
| LED type | IR |
| Mounting type | Wall |
| Product colour | White |
| Volume | 80 dB |
| Weatherproof | Yes |
Operational conditions
| Operating temperature (T-T) | -30 - 40 °C |
| Operating temperature (transmitter) | 0 - 90 °C |
Packaging content
| Manual | Yes |
| Mounting bracket(s) included | Yes |
Performance
| Built-in microphone | Yes |
| Built-in processor | Yes |
| Built-in speaker(s) | Yes |
| Reset button | Yes |
Ports & interfaces
| Connectivity technology | Wired |
| Ethernet interface type | Gigabit Ethernet |
| RJ-45 ports quantity | 1 |
Power
| DC input voltage | 37 - 57 V |
| Power | 7 W |
| Power source type | PoE |
Vendor information
| Brand Name | Ubiquiti |
| Warranty | 2 |
Weight & dimensions
| Bell depth | 6.2 cm |
| Bell height | 6.2 cm |
| Bell weight | 158 g |
| Bell width | 5.4 cm |
Product Details
2026-02-12
New
Data sheet
- Megapixel
- 5 MP
- Reset button
- Yes
- Operating temperature (transmitter)
- 0 - 90 °C
- Bell weight
- 158 g
- Ethernet-Schnittstellentyp
- Gigabit Ethernet
- Internationaler Schutzcode (IP)
- IPX4
- Handbuch
- Yes
- Audiosystem
- 2-way
- Eingebautes Mikrophon
- Yes
- Wetterfest
- Yes
- Sensorart
- CMOS
- LED-Typ
- IR
- Nachtsicht
- Yes
- Konnektivitätstechnologie
- Wired
- Zertifizierung
- CE, FCC, IC
- Stromquellentyp
- PoE
- Eingebauter Prozessor
- Yes
- Beste Verwendung
- Home
- Leistung
- 7 W
- Befestigungsart
- Wall
- Gehäusematerial
- Aluminium/Polycarbonate (PC)
- DC-Eingangsspannung
- 37 - 57 V
- Brand Name
- Ubiquiti
- Warranty
- 2
- Betriebstemperatur (TT)
- -30 - 40 °C
- Produktfarbe
- White
- Eingebaute(r) Lautsprecher
- Yes
- Maximum Bildrate
- 30 fps
- Anzahl der RJ-45-Anschlüsse
- 1
- Eingebaute Kamera
- Yes
- Maximum Videoauflösung
- 1600 x 1200 Pixel
- Horizontales Sichtfeld
- 138 °
- Volumen
- 80 dB
- Auflösung der zweiten Kamera
- 8 MP
- Diagonales Sichtfeld
- 155 °
- Vertikales Sichtfeld
- 114 °
- Beleuchteter Druckknopf
- Yes
- Halterung(en) enthalten
- Yes
- Glockenbreite
- 5.4 cm
- Glockenhöhe
- 6.2 cm
- Glockentiefe
- 6.2 cm
Specific References
- UPC
- 810084692660
- MPN
- UVC-G4 DOORBELL PRO POE KIT-WHITE
