40B00300SA - W128173039

Data sheet

Product color

Black, Red

Windows operating systems supported

Windows 10

Quantity per pack

1 pc(s)

Connectivity technology

Wired

Host interface

Thunderbolt 4

USB 2.0 ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

0

HDMI ports quantity

1

Microphone in

No

Headphone outputs

0

DisplayPorts quantity

2

Combo headphone/mic port

Yes

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

Ethernet LAN data rates

10,100,1000 Mbit/s

Card reader integrated

No

Cable lock slot

Yes

Weight

15.9 oz (450 g)

Harmonized System (HS) code

84733020

Output voltage

20 V

HD type

8K Ultra HD

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

4

Width

8.66" (220 mm)

Height

1.18" (30 mm)

Power source type

AC

Data transfer rate

40 Gbit/s

Certification

cULus, FCC, ICES, NOM

Depth

3.15" (80 mm)

Output current

15 A

Package weight

4.19 lbs (1.9 kg)

Package width

10.6" (270 mm)

Package depth

7.68" (195 mm)

Package height

3.35" (85 mm)

LED indicators

Yes

HDMI version

2.1

DisplayPort version

1.4

DC-in jack

Yes

Maximum digital resolution

7680 x 4320 pixels

VESA mounting

Yes

Power supply

300 W

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

5 - 95%

AC adapter included

Yes

Built-in speaker(s)

No

Cables included

AC

Number of displays supported

4

Manual

Yes

Power consumption (max)

230 W

Cable lock slot type

Kensington

Warranty card

Yes

USB Power Delivery

Yes

USB Power Delivery up to

230 W

Maximum refresh rate

30 Hz

Thunderbolt 4 ports quantity

1

Specific References

EAN13

5715063023860

MPN

40B00300SA
