63D1RAT1EU - W128428053

Data sheet

Product color

Black

HDMI ports quantity

1

Headphone outputs

1

VGA (D-Sub) ports quantity

0

DisplayPorts quantity

1

Headphone connectivity

3.5 mm

Ethernet LAN

Yes

Cable lock slot

Yes

Power supply type

Internal

Display diagonal

31.5"

Display resolution

3840 x 2160 pixels

HD type

4K Ultra HD

LED backlight

Yes

AC input frequency

50 - 60 Hz

AC input voltage

100 - 240 V

Certification

ENERGY STAR® Certified, TCO 9.0, TCO Edge 2.0, EPEAT™ Gold, RoHS
Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Eye Comfort

Package weight

31.7 lbs (14.4 kg)

Touchscreen

No

Compatible operating systems

Windows 10, Windows 11

Height adjustment

Yes

Package width

37.4" (950 mm)

Package depth

5.83" (148 mm)

Package height

20.7" (525 mm)

HDMI version

2.0

DisplayPort version

1.4

VESA mounting

Yes

Power cable length

70.9" (1.8 m)

Panel type

IPS

Built-in speaker(s)

No

Built-in microphone

No

Cables included

AC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-B

Quick start guide

Yes

Power consumption (standby)

0.5 W

Power consumption (off)

0.5 W

Power consumption (typical)

29.5 W

Power consumption (max)

193.7 W

Cable lock slot type

Kensington

Backlight type

W-LED

USB Power Delivery

Yes

USB Power Delivery up to

100 W

USB Type-C DisplayPort Alternate Mode

No

Maximum refresh rate

60 Hz

Tilt angle range

-5 - 23.5°

Native aspect ratio

16:9

Display technology

LED

Response time

6 ms

Screen shape

Flat

Contrast ratio (typical)

1000:1

Display number of colors

1.07 billion colors

Display brightness (typical)

350 cd/m²

Anti-glare screen

Yes

Contrast ratio (dynamic)

3000000:1

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Pixel pitch

0.00717 x 0.00717" (0.182 x 0.182 mm)

Pixel density

140 ppi

Viewable size, horizontal

27.4" (69.7 cm)

Viewable size, vertical

15.4" (39.2 cm)

Color depth

10 bit

Colour gamut standard

DCI-P3

Color gamut

95%

sRGB coverage (typical)

100%

NVIDIA G-SYNC

No

AMD FreeSync

No

Low Blue Light technology

Yes

Built-in camera

No

Detachable stand

Yes

Feet color

Black

Built-in USB hub

Yes

HDMI

Yes

Headphone out

Yes

Tilt adjustment

Yes

On Screen Display (OSD)

Yes

Energy efficiency class (SDR)

F

Energy efficiency class (HDR)

G

Energy consumption (SDR) per 1000 hours

32 kWh

Energy efficiency scale

A to G

Width (with stand)

28.1" (714.2 mm)

Depth (with stand)

9.24" (234.6 mm)

Height (with stand)

23.6" (599.5 mm)

Weight (with stand)

22.3 lbs (10.1 kg)

Width (without stand)

28.1" (714.2 mm)

Depth (without stand)

2.34" (59.5 mm)

Height (without stand)

16.6" (420.9 mm)

Stand included

Yes

Cable management

Yes

Panel mounting interface

100 x 100 mm

Angle of rotation

-90 - 90°

USB hub version

3.2 Gen 1 (3.1 Gen 1)

USB upstream port type

USB Type-B

Number of upstream ports

2

USB Type-A downstream ports quantity

4

AC (power) in

Yes

Adjustable height (max)

6.1" (15.5 cm)

Pivot

Yes

Swiveling

Yes

Swivel angle range

-45 - 45°

Weight (without stand)

15.9 lbs (7.2 kg)

Energy consumption (HDR) per 1000 hours

52 kWh

Audio output

Yes

Built-in KVM switch

Yes

Bezel width (bottom)

0.732" (1.86 cm)

Bezel width (side)

0.0787" (2 mm)

Bezel width (top)

0.0787" (2 mm)

Front bezel color

Black

Response time (fast)

4 ms

Color name

Raven Black

Thunderbolt 4 ports quantity

2

Number of USB Type-B upstream ports quantity

1

HDMI cable length

70.9" (1.8 m)

DisplayPort out quantity

0

DisplayPort cable length

70.9" (1.8 m)

Specific References

UPC

196801194533

EAN13

0196801194533

MPN

63D1RAT1EU
