63D8MAT3EU - W128338161

Data sheet

Product color

Black

Package type

Box

HDMI ports quantity

1

Headphone outputs

1

VGA (D-Sub) ports quantity

1

DisplayPorts quantity

1

Headphone connectivity

3.5 mm

Cable lock slot

Yes

Power supply type

Internal

Display diagonal

23.8"

Display resolution

1920 x 1080 pixels

HD type

Full HD

AC input frequency

50 - 60 Hz

AC input voltage

100 - 240 V

Certification

ENERGY STAR® Certified, TCO 9.0, TCO Edge 2.0, EPEAT™ Gold, RoHS
Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Flicker Free, TÜV Rheinland® Eye Comfort

Package weight

18.7 lbs (8.5 kg)

Touchscreen

No

Compatible operating systems

Windows 10, Windows 11

Height adjustment

Yes

Package width

23.2" (590 mm)

Package depth

7.01" (178 mm)

Package height

16.6" (422 mm)

HDMI version

1.4

DisplayPort version

1.2

VESA mounting

Yes

Power cable length

70.9" (1.8 m)

Panel type

IPS

Built-in speaker(s)

Yes

Built-in microphone

Yes

Cables included

DisplayPort, AC, USB Type-A to USB Type-B

Quick start guide

Yes

Power consumption (standby)

0.5 W

Power consumption (off)

0.5 W

Power consumption (typical)

18 W

Power consumption (max)

60 W

Cable lock slot type

Kensington

Backlight type

W-LED

Maximum refresh rate

75 Hz

Megapixel

2 MP

Tilt angle range

-5 - 23.5°

Native aspect ratio

16:9

Display technology

LED

Response time

6 ms

Screen shape

Flat

Contrast ratio (typical)

1000:1

Display number of colors

16.7 million colors

Display brightness (typical)

250 cd/m²

Anti-glare screen

Yes

Contrast ratio (dynamic)

3000000:1

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Pixel pitch

0.0108 x 0.0108" (0.274 x 0.274 mm)

Pixel density

93 ppi

Viewable size, horizontal

20.7" (52.7 cm)

Viewable size, vertical

11.7" (29.6 cm)

Color depth

8 bit

Colour gamut standard

sRGB

Color gamut

99%

NVIDIA G-SYNC

No

AMD FreeSync

No

Flicker-free technology

Yes

Low Blue Light technology

Yes

Built-in camera

Yes

Number of speakers

2

RMS rated power

6 W

Detachable stand

Yes

Feet color

Black

Built-in USB hub

Yes

HDMI

Yes

Headphone out

Yes

Audio input

Yes

Tilt adjustment

Yes

On Screen Display (OSD)

Yes

Energy efficiency class (SDR)

E

Energy consumption (SDR) per 1000 hours

17 kWh

Energy efficiency scale

A to G

Width (with stand)

21.3" (539.8 mm)

Depth (with stand)

7.86" (199.7 mm)

Height (with stand)

21.4" (542.8 mm)

Weight (with stand)

13.2 lbs (6 kg)

Width (without stand)

21.3" (539.8 mm)

Depth (without stand)

2.12" (53.9 mm)

Height (without stand)

14.3" (363.3 mm)

Stand included

Yes

Cable management

Yes

Panel mounting interface

100 x 100 mm

Angle of rotation

-90 - 90°

USB hub version

2.0 / 3.2 Gen 1 (3.1 Gen 1)

USB upstream port type

USB Type-B

Number of upstream ports

1

USB Type-A downstream ports quantity

4

AC (power) in

Yes

Adjustable height (max)

6.1" (15.5 cm)

Pivot

Yes

Swiveling

Yes

Swivel angle range

-45 - 45°

Weight (without stand)

8.6 lbs (3.9 kg)

Audio output

Yes

Bezel width (bottom)

1.63" (4.14 cm)

Bezel width (side)

0.0827" (2.1 mm)

Bezel width (top)

0.0827" (2.1 mm)

Response time (fast)

4 ms

Color name

Raven Black

Number of USB Type-B upstream ports quantity

1

DisplayPort cable length

70.9" (1.8 m)

Specific References

UPC

196801782235

EAN13

0196801782235

MPN

63D8MAT3EU
