Description
- READY for Intel 14th Gen Processors & AM5
- Unique Design
- Live CPU Temperature Display
- Perfectly Synchronized ARGB
- 360˚ Rotatable Magnetic Pump Head
- Innovative Water Flow Pump Design
- High-Performance Pure Copper Base
- Zalman AF120 Annular Fan with Shark Fin Blades
- Vibrant ARGB Lighting Effect & Pre-installed Anti-vibration rubber pads
- Optimized PWM control
- Aluminum Radiator with Maximum Heat Dissipation Area
- Excellent thermal conductive thermal compound ZM-STC10
Specifications
Design
| Base plate material | Copper |
| Illumination colour | Multi |
| Illumination LED | Yes |
| LED connector type | 3-pin |
| Number of fans | 3 fan(s) |
| Product colour | Black |
| Radiator material | Aluminum |
Performance
| Bearing type | Hydraulic |
| Fan noise level (max) | 29.7 dB |
| Fan speed (max) | 2000 RPM |
| Fan speed (min) | 600 RPM |
| Pulse-width modulation (PWM) support | Yes |
| Pump motor speed | 3000 RPM |
| Suitable location | Processor |
| Supported processor sockets | LGA 1150 (Socket H3)/LGA 1151 (Socket H4)/LGA 1155 (Socket H2)/LGA 1156 (Socket H)/LGA 1200 (Socket H5)/LGA 1700/Socket AM4/Socket AM5 |
| Type | All-in-one liquid cooler |
Vendor information
| Brand Name | Zalman |
| Warranty | 1 |
Weight & dimensions
| Fan dimensions (W x D x H) | 120 x 120 x 26 mm |
| Pump depth | 7.3 cm |
| Pump height | 5.73 cm |
| Pump width | 7.3 cm |
| Radiator depth | 39.7 cm |
| Radiator height | 2.7 cm |
| Radiator width | 12 cm |
Product Details
2025-12-09
New
Data sheet
- Illumination LED
- Yes
- Bearing type
- Hydraulic
- Anzahl Fans
- 3 Lüfter
- LED connector type
- 3-pin
- Geeigneter Standort
- Processor
- Unterstützte Prozessorsockel
- LGA 1150 (Socket H3)/LGA 1151 (Socket H4)/LGA 1155 (Socket H2)/LGA 1156 (Socket H)/LGA 1200 (Socket H5)/LGA 1700/Socket AM4/Socket AM5
- Typ
- All-in-one liquid cooler
- Brand Name
- Zalman
- Warranty
- 1
- Produktfarbe
- Black
- Beleuchtungsfarbe
- Multi
- Grundplattenmaterial
- Copper
- Kühlermaterial
- Aluminum
- Lüftergeschwindigkeit (max.)
- 2000 RPM
- Lüftergeschwindigkeit (min)
- 600 RPM
- Unterstützung für Pulsweitenmodulation (PWM)
- Yes
- Heizkörperhöhe
- 2.7 cm
- Kühlerbreite
- 12 cm
- Kühlertiefe
- 39.7 cm
- Lüfterabmessungen (B x T x H)
- 120 x 120 x 26 mm
- Pump depth
- 2.87" (7.3 cm)
- Pump height
- 2.26" (5.73 cm)
- Pump width
- 2.87" (7.3 cm)
- Lüftergeräuschpegel (max.)
- 29.7 dB
- Drehzahl des Pumpenmotors
- 3000 RPM
Specific References
- ISBN
- 978-1-23456-789-0
- EAN13
- 8809213764981
- MPN
- ALPHA2 A36 BLACK
