Description
The Quantum Laser Nemesis II Series projectors are the perfect combination of energy efficiency and outstanding visual performance, offering brilliant brightness and deep contrast for applications that demand high-quality visuals. Ideal for corporate environments, houses of worship, exhibitions, museums, and art installations, it delivers stunning, immersive imagery with ultimate flexibility. With 360-degree projection, image correction capabilities, and an incredible lifespan, the Quantum Laser Nemesis II Series ensures flawless setup and adaptability in any space, making it the go-to solution for static and dynamic displays.
Incredible Longevity with Virtually Maintenance-Free Operation True-to-Life Visuals for an Immersive and Compelling Visual Experience Seamless Integration Capabilities with Enhanced Connectivity Options 360 Degree And Portrait Projection
Specifications Design Cable lock slot Yes Market positioning Portable Product colour White Product type Short throw projector
Display Features Certification CB, CE, EAC, cTUVus, CCC, FCC, UKCA/WEEE, RoHS International Protection (IP) code IPX6 Noise level 32 dB
Lens system F-number (relative aperture) 2.8 Fixed focal length 7.51 mm Focus Manual Offset 112 % Zoom capability Yes Zoom ratio 1:1 Zoom type Manual
Light source Light source type Laser Service life of light source 30000 h
Multimedia Built-in speaker(s) Yes Number of built-in speakers 1 RMS rated power 15 W
Network Ethernet LAN Yes Ethernet LAN (RJ-45) ports 1 Ethernet LAN data rates 10/100/1000 Mbit/s Wi-Fi No
Operational conditions Operating altitude 0 - 3048 m Operating relative humidity (H-H) 10 - 85 % Operating temperature (T-T) 5 - 40 °C Storage relative humidity (H-H) 10 - 85 % Storage temperature (T-T) -10 - 60 °C
Packaging content AC adapter included Yes Cables included AC/HDMI Manual Yes Remote control included Yes
Ports & interfaces Audio (L/R) in 1 Audio (L/R) out 1 DC-in jack Yes DVI port No HDMI ports quantity 2 HDMI version 2.0 Serial interface type RS-232 USB 2.0 Type-A ports quantity 1 VGA (D-Sub) ports quantity 1
Power AC input frequency 50 - 60 Hz AC input voltage 100 - 240 V Power consumption (max) 195 W Power consumption (standby) 2 W Power consumption (typical) 145 W Power source AC
Projector Contrast ratio (dynamic) 2000000:1 Contrast ratio (typical) 400000:1 Horizontal synchronization (max) 100 kHz Horizontal synchronization (min) 15 kHz Keystone correction, horizontal -15 - 15 ° Keystone correction, vertical -15 - 15 ° Matrix size 0.65 " Native aspect ratio 16:9 Projection distance 1 - 10 m Projection technology DLP Projector brightness 4000 ANSI lumens Projector native resolution 1080p (1920x1080) Supported aspect ratios 16:10/16:9/4:3 Uniformity 85 % Vertical synchronization (max) 0.12 kHz Vertical synchronization (min) 0.024 kHz
Storage Vendor information Brand Name Infocus Warranty 1
Video Full HD No Supported graphics resolutions 3840 x 2160
Product Details
Availability date:
2026-02-02
Condition
New
Data sheet
Market positioning
Portable
Handheld remote control
Yes
Zoom capability
Yes
Native aspect ratio
16:9
Contrast ratio (dynamic)
2000000:1
Projector brightness
4000 ANSI lumens
Projection distance
39.4 - 393.7" (1 - 10 m)
Service life of light source
30000 h
Zoom ratio
1:1
Supported aspect ratios
16:10/16:9/4:3
Horizontal synchronization (min)
15 kHz
Vertical synchronization (min)
0.024 kHz
Ethernet-LAN-Datenraten
10/100/1000 Mbit/s
Anzahl der eingebauten Lautsprecher
1
RMS-Nennleistung
15 W
Kontrastverhältnis (typisch)
400000:1
Anzahl der HDMI-Anschlüsse
2
DVI-Anschluss
No
Ethernet-LAN-Anschlüsse (RJ-45)
1
Produktart
Short throw projector
Inklusive Netzteil
Yes
DC-Eingangsbuchse
Yes
Internationaler Schutzcode (IP)
IPX6
Focus
Manual
Wi-Fi
No
Geräuschpegel
32 dB
Handbuch
Yes
Kabel enthalten
AC/HDMI
Typ der seriellen Schnittstelle
RS-232
Feste Brennweite
7.51 mm
Ethernet-LAN
Yes
Zertifizierung
CB, CE, EAC, cTUVus, CCC, FCC, UKCA/WEEE, RoHS
AC-Eingangsfrequenz
50 - 60 Hz
AC-Eingangsspannung
100 - 240 V
Stromverbrauch (typisch)
145 W
Kartenleser integriert
No
Schlitz für Kabelschloss
Yes
Full-HD
No
Eingebautes Display
No
Stromverbrauch (Standby)
2 W
Betriebshöhe
0 - 3048 m
Stromverbrauch (max.)
195 W
Energiequelle
AC
HDMI-Version
2.0
Unterstützte Grafikauflösungen
3840 x 2160
Anzahl der VGA (D-Sub) Anschlüsse
1
Brand Name
Infocus
Warranty
1
Betriebstemperatur (TT)
5 - 40 °C
Lagertemperatur (TT)
-10 - 60 °C
Relative Luftfeuchtigkeit bei Lagerung (HH)
10 - 85 %
Relative Luftfeuchtigkeit im Betrieb (HH)
10 - 85 %
Produktfarbe
White
Eingebaute(r) Lautsprecher
Yes
Audio (L/R) ein
1
Audio (L/R)-Ausgang
1
Lichtquellentyp
Laser
Native Auflösung des Projektors
1080p (1920x1080)
Projektionstechnik
DLP
Versatz
112 %
Keystone-Korrektur, horizontal
-15 - 15 °
Keystone-Korrektur, vertikal
-15 - 15 °
Matrixgröße
0.65 "
Anzahl der USB 2.0 Typ-A-Anschlüsse
1
Gleichmäßigkeit
85 %
Horizontale Synchronisation (max.)
100 kHz
Vertikale Synchronisation (max.)
0.12 kHz
Zoom-Typ
Manual
F-number (relative aperture)
2.8
Specific References
UPC
850053009440
MPN
IN1028ST
