AV2-500WH

The Neomounts AV2-500WH is a universal videobar kit for screens with a minimal size of 43? and VESA hole pattern ranging from 200x200 to 800x600 mm. The very sturdy, stable and versatile kit has a maximum weight capacity of 10 kg and can be installed either above or below the screen. For maximum adaptability, both the videobar support and the backplate brackets can be independently adjusted in height.

The AV2-500WH videobar kit is compatible with most videobars*, PTZ cams and soundbars, including Logitech Rally Plus speakers. To ensure a wide mounting applicability, the mounting holes can vary in width and height. The VESA frame can be adjusted both in height and width (200/400/600/800) and can be installed on wall, floor and even desk or ceiling mounts. Despite the numerous choices, installation is easy, aided by ruler-guided alignment for a seamless screen installation.
\t
* The Neomounts AV2-500WH videobar kit is universal and suitable for any type of videobar, regardless of make or model, within the range of the mounting bracket (see line drawing). In addition, the AV2-500WH is optimised for the following specific videobars:

- Bose Professional VB1 and VB-S
- Neat Bar and Bar Pro
- Poly Studio, Studio X70 and Studio X30
- Jabra Panacast 50
- Logitech Meetup, Rally Bar, Rally Bar Mini, Rally Bar Huddle and Rally Plus
- Cisco Webex Room Kit Plus
- Yealink MSpeaker II, MeetingBar A30, MeetingEye 400 and MeetingEye 600

Refer to the online manual for specific model or mounting size compatibility.

Neomounts AV2-500WH. Product type: Camera mount, Product color: White, Placement supported: Wall/ceiling. Maximum weight capacity: 22 lbs (10 kg), Width: 35.4" (900 mm), Depth: 1.22" (31 mm). Country of origin: China, Quantity per master (outer) case: 3 pc(s), Master (outer) case weight: 47.4 lbs (21.5 kg). Package width: 8.66" (220 mm), Package depth: 3.31" (84 mm), Package height: 36.5" (926 mm)

Product type	Camera mount
Product color	White
Placement supported	Wall/ceiling
Minimum screen size	43"
Maximum screen size	110"
Panel mounting interface	200 x 200,200 x 400,400 x 400,400 x 600,200 x 300,600 x 200,600 x 300,600 x 400,800 x 200,800 x 400,400 x 300,400 x 500,600 x 500,600 x 600,800 x 500,800 x 600,400 x 200
Brand compatibility	Any brand
Compatible products	Bose Professional VB1 en VB-S Neat Bar en Bar Pro Poly Studio, Studio X70 en Studio X30 Jabra Panacast 50 Logitech Meetup, Rally Bar, Rally Bar Mini, Rally Bar Huddle en Rally Plus Cisco Webex Room Kit Plus Yealink MSpeaker II, MeetingBar A30, MeetingEye 400 en MeetingEye 600
Housing material	Steel
Maximum weight capacity	22 lbs (10 kg)
Width	35.4" (900 mm)
Depth	1.22" (31 mm)
Height	16.4" (416 mm)
Weight	22.7 lbs (10.3 kg)
Country of origin	China
Quantity per master (outer) case	3 pc(s)
Master (outer) case weight	47.4 lbs (21.5 kg)
Master (outer) case length	9.37" (238 mm)
Master (outer) case width	10.4" (263 mm)
Master (outer) case height	37.2" (944 mm)
Master (outer) case net weight	46.3 lbs (21 kg)
Harmonized System (HS) code	7326909890
Quantity per EUR-pallet	45 pc(s)
Total carbon footprint (kg of CO2e)	20.05
Warranty period	5 year(s)
Package width	8.66" (220 mm)
Package depth	3.31" (84 mm)
Package height	36.5" (926 mm)
Package weight	15.9 lbs (7.2 kg)
